Pixy2, Smart Vision Camera

This item can only be purchased in multiples of 25

Product Overview

These blind steel rivets are a perfect, strong choice for creating frames when using our 1in. Gussets paired with up to .125" wall aluminum tubing. These steel rivets won't let you down when you need them most!

Specifications

• Diameter: 3/16 in.
• Drill Size For Hole: #11
• Finish: Zinc
• Grip Range: 0.126-0.25 in.
• Head: Buttonhead
• Hole Size: 0.192-0.196 in.
• Length: 0.45 in.
• Mandrel Material: Steel
• Material: Steel
• Rivet Style: Blind
• Weight: 0.0094

This item can only be purchased in multiples of 25

#10-32 x 0.5 in. long Socket Head Cap Screw

Specifications

• Finish: Zinc
• Head: Socket Cap
• Length: 0.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.1 lbs

This item can only be purchased in multiples of 25

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: #10-32
• Thickness: 0.249"
• Thread: Fine
• Thread Size: 32
• Type: Nylon Insert Lock Nut
• Wrench Size: 3/8"

Aluminum Clamp On Shaft Collar, 3/8" Hex Bore

This is a wide, heavy duty, collar clamp.

Specifications:

• Material: Aluminum
• Diameter: 0.875 - 1"
• Thickness: 0.3 - 0.34"
• Weight: 0.02 Lbs

This new custom designed collar clamp has been designed specifically with FIRST Robotics Competition teams in mind. This product is Out of Stock until Mid March

We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.

On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.

Specifications

• Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
• Material: 6061-T6 Aluminum
• Thickness: 0.125 in

Documents

Layout Print(s)

am-3860 90 Gusset REV2.PDF

am-4158 1IN Tee Gusset.PDF

am-4159 1IN Quad Gusset.PDF

am-4160 1IN 30deg Gusset.PDF

am-4161 1in 45deg Gusset.PDF

am-4162 1in 60deg Gusset.PDF

am-4163 1in 120deg Gusset.PDF

am-4164 1in 135deg Gusset.PDF

am-4165 1in 150deg Gusset.PDF

am-4166 1IN Sport Double Bearing Mount.PDF

am-4167 1IN 57Sport Side Mount Gusset.PDF

am-4168 1IN Bearing Side Mount Gusset.PDF

CAD File(s)

am-3860 90 Gusset REV2.STEP

am-4158 1IN Tee Gusset.STEP

am-4159 1IN Quad Gusset.STEP

am-4160 1IN 30deg Gusset.STEP

am-4161 1in 45deg Gusset.STEP

am-4162 1in 60deg Gusset.STEP

am-4163 1in 120deg Gusset.STEP

am-4164 1in 135deg Gusset.STEP

am-4165 1in 150deg Gusset.STEP

am-4166 1IN Sport Double Bearing Mount.STEP

am-4167 1IN 57Sport Side Mount Gusset.STEP

am-4168 1IN Bearing Side Mount Gusset.STEP

This is the "500EX Hex Hub" the bore is a 1/2" Hex Hole. It is a slightly different version of the 500 Hex Hub. It is manufactured differently, as it is extruded. Also, there is a 1.124" diameter boss on each side of the hub flange, providing a location for 1.125" bore flat sprockets. Are you having a hard time keeping your sprocket concentric with your hub? This hub is the trick.

This is the hub featured in the 2014 and 2015 Kit of Parts Drive Chassis and fits all AndyMark wheels.

Specifications:

• Material: 6063 Aluminum
• Bore: 1/2" Hex
• Bolt Pattern: 0.204" diameter holes, evenly spaced on a 1.875" diameter bolt circle
• Outside diameter: 2.25"
• Weight: .088

This updated version of the AndyMark 775 RedLine Motor is an even faster and more powerful version of this popular 775-class motor platform. With a power rating of up to 363W, this motor is capable of delivering even more immense power in the same small lightweight package over the previous version. This ball-bearing supported, air cooled motor is best used in high-speed applications where the motor will not be stalled for long periods such as shooters, conveyors, and intake mechanisms. With sufficient care and attention to your application's traction limit, this motor can be effective in FRC drive applications as well.

This variation of the RedLine comes with a 12 tooth, 32 DP pinion already pressed on allowing this motor to be installed into EVO Slim 4 RedLine, EVO Shifter 4 RedLine and DeCIMate gearboxes. Not only does this take the risk of damaging the motor during pinion installation out of your hands, it also means that this counts as a COTS part in FRC, and bringing these as spares to your competition won't count against your weight allowance for 2019.

Product Usage:
Motors need air flow to keep cool. A hot motor won't last nearly as long, or deliver the power it once did new. To keep a RedLine cool and in great shape, use a 775 Vent Plate Spacer, am-3650 when mounting to a custom gearbox. All of our gearboxes that use this motor have vent plate spacers included with your purchase or include sufficient venting machined in.

Useful Additional Parts:

• RedLine Encoder Kit, am-3773
• 12 Tooth 32 DP Pinion, am-3657
• M4 x 0.7 10 mm Mounting Screw, am-1264
• Vent Plate for keeping this motor cool and functional - 775 Vent Plate Spacer, am-3650
• Fantastic Gearbox Pairing Options:
  • 57 Sport Gearboxes
  • DeCIMate Gearbox
  • EVO Slim for RedLine
  • EVO Shifter for RedLine

Motor has the following information laser etched on the flux ring:
Manufacturer Part number: DF-30F-2003
Logo: AndyMark Logo
AndyMark Part Number: am-3775a
Voltage: 12VDC
Date Code: YYWWD

Specifications

• Bolt Pattern: 2 M4x0.7 Holes on a 29 mm diameter bolt circle
• Diameter: 1.744 in.
• Diametral Pitch: 32
• Face Width: 0.625 in.
• Free Speed: 21020 RPM
• Gear Length: 0.755 in.
• Gear Material: 1117 Steel
• Gear Weight: 0.014 lbs
• Length: 3.826 in.
• Maximum Power: 380 Watts (+/- 10%)
• No Load Current: 3.8 AMPs
• No Load Free Speed : 21020 RPM (+/- 10%)
• No Load RPM: 21020 RPM (+/- 10%)
• Output Shaft Diameter: 5 mm
• Output Shaft Length: 0.346 in.
• Pitch Diameter: 0.375 in.
• Pressure Angle: 20 Degrees
• Stall Current: 130 AMPs
• Stall Torque: 0.7 N-m (6.2 in-lbs) (+/- 10%)
• Teeth: 12
• Voltage: 12 Volts DC
• Weight: 0.819 lbs

Documents

CAD File(s)

am-3775a_12T 775 RedLine with 12T Pinion.STEP

Layout Print(s)

am-3775a_12T 775a RedLine with 12T Pinion.PDF

This motor is often used in power seats for raising the seat up and down. It is perfect for precise positioning and not back driving when power is cut. This motor features an integrated hall sensor to enable accurate positioning feedback. The wire harness can be purchased individually as am-3548 and the motor can be purchased individually as am-3493.

Usage:
WPI has some great documentation on how to interface and mount this motor. http://wpilib.screenstepslive.com/s/4485/m/63630/l/679357-bosch-seat-motor

Specifications:

• Manufacturer: Bosch LLC
• Manufacturer part number: 6004RA3194 (motor only)
• No Load Speed: 24 RPM
• No Load Current: <3A
• Stall Torque: 22Nm 16.2 ft-Lbs
• Max Stall Current: 12A
• Motor Gear Ratio: 174.9:1
• Weight: 0.87 Lbs

Everyone's favorite motor for indexing, and small jobs in tight spaces, is back with everyone's favorite shaft, 1/2 in. hex!

This motor and gearbox combo originally came from a snowblower assembly, but now has a custom shaft just for FRC. Use our half inch hex hub or a 1/2 in. hex bore wheel to transfer power directly, or sprocket and chain to drive the mechanism of your dreams! The shaft also now has a #10-32 hole in the end for easy hub/sprocket retention.
