The Motor Mount Plate is used with the Maverick 12V DC Gear Motor (Part# 75001) to attach it inside the anyone of the U Channels 76010 to 76018. This is an example of a chassis with 4 motors mounted inside the U-Channel using a Motor Mounting Plate.
May be used with 6mm D-Shape Shaft to secure wheels in their position.
Specifications:
Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.
The Studica U Channel is 3mm thick and has a 48mm x 48mm profile. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.
On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.
Layout Print(s)
am-3860 90 Gusset REV2.PDF
am-4158 1IN Tee Gusset.PDF
am-4159 1IN Quad Gusset.PDF
am-4160 1IN 30deg Gusset.PDF
am-4161 1in 45deg Gusset.PDF
am-4162 1in 60deg Gusset.PDF
am-4163 1in 120deg Gusset.PDF
am-4164 1in 135deg Gusset.PDF
am-4165 1in 150deg Gusset.PDF
am-4166 1IN Sport Double Bearing Mount.PDF
am-4167 1IN 57Sport Side Mount Gusset.PDF
am-4168 1IN Bearing Side Mount Gusset.PDF
CAD File(s)
am-3860 90 Gusset REV2.STEP
am-4158 1IN Tee Gusset.STEP
am-4159 1IN Quad Gusset.STEP
am-4160 1IN 30deg Gusset.STEP
am-4161 1in 45deg Gusset.STEP
am-4162 1in 60deg Gusset.STEP
am-4163 1in 120deg Gusset.STEP
am-4164 1in 135deg Gusset.STEP
am-4165 1in 150deg Gusset.STEP
am-4166 1IN Sport Double Bearing Mount.STEP
am-4167 1IN 57Sport Side Mount Gusset.STEP
am-4168 1IN Bearing Side Mount Gusset.STEP
The Studica Square Beam is 8mm by 8mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
This gear is used as the input pinion gear for the EVO Shifter. This gear is a tight press fit onto a CIM gear, and requires at minimum a 3-ton arbor press to install. If a CIM motor with this gear pre-installed interests you, check out am-0255_15T. Specifications:
The WorldSkills Mobile Robotics Collection – Shanghai 2022 by Studica is the authorized collection for the WorldSkills Mobile Robotics Competition. Featuring the Studica VMX Robotics Controller for WorldSkills, the Titan Quad Motor Controller and Servo Power Block. This comprehensive Collection also includes electronics, accessories, motors, servos, mounts, U-Channel, mounting plates, flat brackets, irregular brackets, and flat beams. You'll also find gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs. Includes Everything You Need (Over 1500 components).
Download brochure and BOM
The WorldSkills Mobile Robotics Junior Collection by Studica is the authorized collection for the WorldSkills Asia Mobile Robotics Junior Competition. This comprehensive Collection includes over 1,400 items including controller, electronics, motors, structure, gears, sprockets, pulleys, belts, axles, slides, rack & pinion, wheels, bushings, bearings, coupling, collars, spacers, screws, nuts, and standoffs.
Includes,
The Studica VMX FRC-compatible Training Bot (FRC Trainer) is a smaller, sturdy, lightweight, and less expensive robot than your typical FRC robot. If you have a large FRC team, often only a handful of students get to learn how to create and program your team’s costly competition robot. The FRC Trainer solves this problem and is ideal for groups of two to three to participate in hands-on learning in a classroom environment. Schools can equip their labs with multiple FRC Trainers, benefiting from the great value and compact size. Students can even take it home with them!
This affordable solution is intended for:
The FRC-compatible Trainer is an intelligent and autonomous robot that uses the VMX Advanced Robotics Controller which can be programmed in C++ and Java. VMX’s multitude of modern digital communications interfaces and Linux-based operating system allow users to directly access most modern devices (e.g., Intel RealSense tracking and depth cameras and LIDAR).
Download BOM here
