Chain Breaker Tool

#25 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #25
• Pitch: 0.250 inch
• Weight: 0.01 lbs

#25 Half Link. Also known as #25 Offset Link.

Specifications:

• Material: Steel
• Style: Roller Chain with interted pin
• Type: Half Link
• Size: #25
• Pitch: 0.25 inch
• Weight: 0.01 lbs

Secure Powerpole connections with these easy to use Powerpole Clips. Don't worry about your power pole connections coming loose during those important times and when the time comes to swap components, the clip comes out easily. Works for PP15, PP30 and PP45.

This item can only be purchased in multiples of 10

We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.

On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.

Specifications

• Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
• Material: 6061-T6 Aluminum
• Thickness: 0.125 in

Documents

Layout Print(s)

am-3860 90 Gusset REV2.PDF

am-4158 1IN Tee Gusset.PDF

am-4159 1IN Quad Gusset.PDF

am-4160 1IN 30deg Gusset.PDF

am-4161 1in 45deg Gusset.PDF

am-4162 1in 60deg Gusset.PDF

am-4163 1in 120deg Gusset.PDF

am-4164 1in 135deg Gusset.PDF

am-4165 1in 150deg Gusset.PDF

am-4166 1IN Sport Double Bearing Mount.PDF

am-4167 1IN 57Sport Side Mount Gusset.PDF

am-4168 1IN Bearing Side Mount Gusset.PDF

CAD File(s)

am-3860 90 Gusset REV2.STEP

am-4158 1IN Tee Gusset.STEP

am-4159 1IN Quad Gusset.STEP

am-4160 1IN 30deg Gusset.STEP

am-4161 1in 45deg Gusset.STEP

am-4162 1in 60deg Gusset.STEP

am-4163 1in 120deg Gusset.STEP

am-4164 1in 135deg Gusset.STEP

am-4165 1in 150deg Gusset.STEP

am-4166 1IN Sport Double Bearing Mount.STEP

am-4167 1IN 57Sport Side Mount Gusset.STEP

am-4168 1IN Bearing Side Mount Gusset.STEP

Do you need an odd number of chain links? Tired of dealing with cotter pins in old school "half links"?  Love using the DarkSoul or ARC chain tool for everything? These are the links for you!

These links add one and a half links to a run of chain making for easier cleaner alternative to half links. Use a chain splicing tool or two master links to install them. No more lost matches from a failed half link!

Specifications

• Chain Size: #25, #35
• Material: Steel
• Pitch: 0.25 in., 0.375 in.
• Style: Roller Chain

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

The Motor Mount Plate is used with the Maverick 12V DC Gear Motor  (Part# 75001) to attach it inside the anyone of the U Channels 76010 to 76018. This is an example of a chassis with 4 motors mounted inside the U-Channel using a Motor Mounting Plate.

• Step File

Made of aluminum, the Studica Clamping Shaft Hub is used with flex and drive wheels

Specifcation:

• Material: 6061-T6 Aluminum
• 6mm ID
• Hole pattern for connecting to structure
• Step File

May be used with 6mm D-Shape Shaft to secure wheels in their position.


Specifications:

• Φ20.0mm*8.0mm thick
• 1*M3 thread for M3 SHCS on the clamp side
• Φ6.0mm D hole
• AL6061-T6
• Step File

Compliant wheels are not intended for moving robots, but moving objects. Compliant wheels give way to allow rigid objects to be manipulated easily. A line of multiple wheels on a driven hex axle creates a very effective roller that ignores variations in the objects being driven. This makes for high-performance intakes and internal conveyors.

Different durometer ratings give each wheel unique characteristics. Green wheels (35A durometer) are the softest and most compliant around objects, maroon (45A), blue (50A), and black (60A) wheels are increasingly firm. The increased firmness also allows the latter wheels to carry a higher RPM rating. Check out the downloads tab for a chart showing wheels and their maximum RPM.

Specifications

• Bore: 0.375 in. Hex, 0.50 in. Hex, 5 mm Hex
• Core Material: Polycarbonate
• Diameter: 2.25 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.08 lbs
• Width: 1 in.

Documents

Layout Print(s)

am-3949 2.25IN 500Hex HD Compliant Wheel REV3.PDF

am-3950 2.25IN 375Hex HD Compliant Wheel REV3.PDF

am-4536 2.25in HD 5mm Hex Molded Compliant Wheel.PDF

CAD File(s)

am-3949 2.25IN 500Hex HD Compliant Wheel.STEP

am-3950 2.25IN 375Hex HD Compliant Wheel.STEP

am-4536 2IN OverMolded 5mm Hex Compliant Wheel.STEP
