AM14U4 Upgrade Kit Falcon Hardware

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

The MINI® Fuse is the standard for vehicle circuit protection. Its miniature design meets the need for more circuits to be protected while utilizing less space, and its ability to cope with high temperatures in adverse environments makes the MINI® Fuse of recommended choice for protection.

This mini fuse can be used in our Power Pole Distribution Board (am-3699), as well as a replacement in the Power Distribution Panel (am-2856)

Anderson Power Products Connector with 2 contacts.

Specifications:

• Material (APP Connector): Red Plastic
• Weight: 0.060
• Mounting holes: 0.15" diameter, 3/4" apart

Included Hardware:

• One - SB-50A red plastic connector
• Two - Anderson Power Products crimp contacts (sized for 6 gauge wire)

This Inline Chain Tensioner for #25 series roller chain is perfect to adjust the desired tension in a long run of chain on mechanisms such as elevators and arms. This is ideal where there is at least a ~3" section of chain that never passes over a sprocket in a given mechanism. Pair this with two #25 Master Links and integrate this to your project for an easy-to-use chain tension solution!

The design of this product was inspired by Misumi's Chain Turnbuckles. This product has been improved to be compatible with imperial-sized wrenches.

Specifications

• Chain Size: #25

Documents

CAD File(s)

am-3915_25 25 Chain Inline Tensioner REV3.STEP

Layout Print(s)

am-3915_25 #25 Chain Inline Tensioner REV3.PDF

Easy to install panel mount volt meter features a bright easy to read red display. Monitor DC voltage from 5-30 VDC. Fits standard 1-1/8" diameter hole. Low 10mAh current draw. Rear mounted F2 faston tab connections.

Specifications:

• Length: 2.35"
• Width: 1.67"
• Mounting Hole Size: 0.14"
• Weight: 0.04
• Voltage Range: 5-30VDC
• Current Draw: 10mAh

Omni-directional wheels in the smallest diameter offered by any common FIRST Robotics Competition or FIRST Tech Challenge supplier.

These 50 mm / 2 inch omni wheels features two different durometers:

• Soft 35A rollers for high traction
• Hard 90A rollers for long life

They also have a standard 14 mm Hex Bore, letting you choose between 3 different bores:

• 0.375 in. Hex - includes 14 mm Hex to 3/8 in. Hex Adapter (am-3905)
• 0.5 in. Hex - includes 14 mm Hex to 1/2 in. Hex Adapter (am-3904)
• 14 mm Hex - no adapters included

Stack several of these wheels on a shaft to craft an unstoppable intake system for your robot that can be used to center game pieces.

Specifications

• Bore: 0.375 in. Hex, 0.5 in. Hex, 14 mm Hex
• Diameter: 50 mm, 1.96 in.
• Durometer: 35A, 90A
• Load Capacity: 10 lbs
• Material: Glass Filled Nylon Body, Acetal Inserts, Thermoplastic Elastomer Rollers
• Weight: 0.076 lbs

This true HD camera gives you bright and colorful video, and makes it easy to post to your favorite social sites.

Microsoft Lifecam HD-3000 Webpage

Specifications:

• Manufacturer: Microsoft
• Model Number: HD-3000
• Connection Type: USB 2.0
• Image Sensor: CMOS
• Maximum Image Resolution: 1280 x 720
• Video Capture Resolution: 1280 x 720
• Frame Rate: 30 fps
• Focus Settings: Fixed focus from 0.3 to 1.5 meters
• Size: 1.6 x 1.8 x 4.3 inches
• Weight (Camera): 0.2 pounds

Features (From Manufactuer Website):

• Certified for Skype. Do more together in HD, with Skype certified HD LifeCams from Microsoft.
• 720p HD video chat for a true HD-quality experience.
• Widescreen 16:9 format offers cinematic video recording.
• TrueColor technology automatically delivers bright and colorful video, in virtually all lighting conditions.

This 120 Amp Circuit breaker forms the main circuit breaker for FIRST Robotics Competition robots. It can protect your robot or other system from drawing so much current that systems receive more damage. Of course, we highly recommend using circuit breakers downstream rated for less to protect your motors, speed controllers, and control system components.

Specifications:

• Weight: 0.24 pounds
• Size: 2.9 x 1.9 x 1.5 inches
• Surface Mount Style
• Terminal Supply part number: CB3-SM-120
• Type III Breaker Manual Reset
